NACM2010 STAINLESS STEEL CHAIN
|
Nominal Chain Size |
Material Diameter |
Working Load Limit(Max.) |
Proof Test (Min.) |
Min. Breaking Force |
Inside Length (Max.) |
Inside Width (Min.) |
|||||||
|
in |
mm |
in |
mm |
lbs |
kg |
lbs |
kN |
lbs |
kN |
in |
mm |
in |
mm |
|
5/32 |
4.0 |
0.156 |
4.0 |
500 |
230 |
1,000 |
4.5 |
2,000 |
9.0 |
0.94 |
23.9 |
0.25 |
6.4 |
|
3/16 |
5.0 |
0.197 |
5.0 |
930 |
420 |
1,860 |
8.3 |
3,720 |
16.6 |
0.98 |
24.8 |
0.30 |
7.7 |
|
7/32 |
5.5 |
0.218 |
5.5 |
1,200 |
540 |
2,400 |
10.7 |
4,800 |
21.4 |
0.98 |
24.8 |
0.25 |
6.4 |
|
1/4 |
6.5 |
0.250 |
6.5 |
1,570 |
710 |
3,140 |
14.0 |
6,280 |
28.0 |
1.24 |
31.5 |
0.30 |
7.7 |
|
9/32 |
7.0 |
0.276 |
7.0 |
2,000 |
910 |
4,000 |
17.8 |
8,000 |
35.6 |
1.24 |
31.5 |
0.34 |
8.6 |
|
5/16 |
8.0 |
0.315 |
8.0 |
2,400 |
1,090 |
4,800 |
21.4 |
9,600 |
42.8 |
1.29 |
32.8 |
0.38 |
9.8 |
|
3/8 |
10.0 |
0.394 |
10.0 |
3,550 |
1,610 |
7,100 |
31.6 |
14,200 |
63.2 |
1.38 |
35.0 |
0.55 |
14.0 |
|
7/16 |
12.0 |
0.472 |
12.0 |
5,400 |
2,450 |
10,800 |
48.1 |
21,600 |
96.2 |
1.64 |
41.6 |
0.65 |
16.6 |
|
1/2 |
13.0 |
0.512 |
13.0 |
6,500 |
2,950 |
13,000 |
58.0 |
26,000 |
116.0 |
1.79 |
45.5 |
0.62 |
15.8 |
|
5/8 |
16.0 |
0.630 |
16.0 |
9,800 |
4,450 |
19,600 |
87.0 |
39,200 |
174.0 |
2.20 |
56.0 |
0.79 |
20.0 |
|
3/4 |
20.0 |
0.750 |
20.0 |
15,000 |
6,820 |
30,000 |
134.0 |
60,000 |
268.0 |
2.85 |
72.4 |
0.98 |
31.7 |
|
1 |
26.0 |
1.000 |
26.0 |
23,250 |
10,570 |
46,500 |
207.0 |
93,000 |
414.0 |
3.58 |
90.0 |
1.25 |
55.0 |
